Comag Thickness Planer - second-hand not available

Machine number 5923

Manufacturer

Comag

Model

Condition

used

This machine is not available anymore.

We hope one of the following machines fits your needs:

reserved Solid Wood Slat Gluing Line - second-hand Kraft
reserved Drying Plant - second hand Nardi
Longitudinal Profiling Machine for Parquet - second-hand A. Costa Mistral PA6
Surface planer - second-hand Rojek RFS 410
Four Side Planer - second-hand Weinig Unimat 23
Cross Profiling Machine / End Profiling Machine - second-hand Marinus Powermax 300 Endmatcher
reserved Calibrating Milling Machine / Planing Machine for Parquet - second-hand Ledinek Rotoles 400 DS
Planer and moulder / Four-sided planer - second-hand SCM Superset XL
Four-sided planer and moulder - second-hand SCM Superset XL

Do you have any questions?

not available

Description

Thickness Planer
make Comag
type H6

working width 630 mm
working height max. 200 mm
max. chippings thickness 8 mm
2 feed speeds, 12 and 24 m/min.
two-stage gear drive feed- in chrome-nickel running in oil bath
safety knife shaft with 4 knives
planer knife speed 6000 rpm
planing knife Ø 120 mm
feed roller: steel ribbed
pull-out roller: steel
planing table with 2 slide rollers
planing table length 1050 mm
slide rollers adjustment by handwheel
motor power drive 6,0 kW
thickness adjustment manually / handwheel
thickness adjustment scale
heavy stable cast iron construction
feed, table rollers and table spindle are ball-bearing
extraction nozzle Ø 150 mm
instruction manual
