Marinus Cross-Cut and End Face Profiling Machine - second-hand not available

Descripción

Cross-Cut and End Face Profiling Machine
make Marinus
type Promax

Year of manufacture 2010

End profiling machine for parquet production, which performs cutting to length, trimming of defects and profiling on the end faces in one pass.

Specifications of the parts to be processed:
- min. width 60 mm
- max. width 400 mm
- min. length 500 mm
- max. length 6000 mm
- min. thickness 10 mm
- max. thickness 25 mm

Length measurement of the workpieces:
Total length and surface are measured during production.

Standard programming:
The machine has 2 main programmes:
1 end profiling 2 caps
Both main programs have program for:
Variable lengths: Defects are cut out, final products have variable lengths.

This machine meets the following specifications:
- Stable heavy construction.
- Feed-through mechanism with accurate positioning.
- Clamping for precise and vertical machining.
- PLC control Omron.
- Clear and simple operation.
- 2 servo-drives.
- 2 sawing motors (5.5 kW).
- 2 milling motors frequency converter 7.5 kW /200 Hz / 12,000 rpm.
- 1 gear motor frequency converter 0.75 kW.
- 1 drum motor 0.18 kW.
- 26 pneumatic cylinders.
- Valve terminal 8 positions.
- 9 sensors.
- Machine completely closed with door switch.
- Machine compliant with CE machinery directive.

The machine includes a waste conveyor belt.

Tools:
We offer optional tools with inserts and saw blades.
Also suitable infeed and outfeed transports can be offered.
