OKOMA Window Line - second-hand not available

Numéro de machine 6073

Fabricant

OKOMA

Modèle

UF

Catégorie

Machines de fraisage

Condition

d'occasion
OKOMA Window Line - second-hand UF main picture not available

Description

Window Line
make. OKOMA
type UF

spindle length: min. 0 mm, max. 125 mm at tool diameter 320 mm
wood width: min. 45 mm, max. 140 mm (tool dependent)
wood thickness: min. 50 mm, max. 80 mm

with 1 slot spindle and 2 milling units
spindle diameter 40 mm

crosscut saw:
spindle above
three-phase drive 3 kW

slot spindle:
power 7,5 kW, speed 4,000 rpm
effective length 252 mm
tool diameter max. 320 mm

roller table with DC motor
speed ​​in front of cross-cut saw and slot-spindle infinitely adjustable
workpiece clamping with 2 clamping cylinders from above pneumatic
tiltable range 0 - 60 degrees

angular transfer:
2 pieces lowerable feed rollers for pulling inthe profile part

profile spindle:
spindle arrangement on the right
power 11 kW
speed ​​7,000 rpm
direction of rotation mating
effective length 252 mm

glassstrip saw:
saw blade 250x30x3,0 mm, NL 7, TK 44
speed ​​3,000 rpm
spindle diameter 30 mm
clamping length 13 mm
drive three-phase motor 3 kW

control panel:
selection of automatic and manual functions for:
Rollertable
crosscut saw
slot spindle
profile spindle
feed
