Mayer / Format 4 Horizontal panel saw / Horizontal pressure beam saw - second-hand not available

Machine number 7453

Manufacturer

Mayer / Format 4

Model

PS 80 / Kappa Automatik 80

Construction year

2015

Category

Saws

Condition

used

This machine is not available anymore.

We hope one of the following machines fits your needs:

Mayer / Format 4 Horizontal panel saw / Horizontal pressure beam saw - second-hand PS 80 / Kappa Automatik 80 main picture not available

Description

Horizontal panel saw / Horizontal pressure beam saw
make Mayer / Format 4
type PS 80 / Kappa Automatic 80

year of manufacture 2015
Operating hours only approx. 175

cutting length: 3200 × 3200 mm
cutting height: 78 mm with groove function

Saw blade quick clamping
Scorer quick clamping

Cutting direction: In direction of angle stop

Angle fence: Left version

Saw carriage:
Workpiece length detection via 2 lasers
Feed speed stepless 5 - 100 m/min

Return 130 m/min

Saw blade:
Min. 250x30x4.4 mm
Max. 320x30x4.4 mm

Scorer:
150x30 mm conical

Collets:
7 pieces

Support tables:
3 large tables air-supported.
2400x600 mm
each with 1 roller at the head end

Software included:
- single cut program
- strip cut program
- format program
- grooving program
- Label configurator
- Label printing after executed cut

Optimization:
Ardis software on operator terminal

Available: May 2022
