Giben Horizontal Panel Sizing Saw with Lift Table Feeding - second-hand not available

Machine number 7586

Manufacturer

Giben

Model

Prisma 3000

Category

Saws

Condition

used

This machine is not available anymore.

We hope one of the following machines fits your needs:

Giben Horizontal Panel Sizing Saw with Lift Table Feeding - second-hand Prisma 3000 main picture not available

Description

Horizontal Panel Sizing Saw with Lift Table Feeding System
make Giben
type Prisma 3000

year of manufacture 2010

pressure beam panel saw for processing wood, plastics and other materials in furniture production

cutting length max. 4600 mm
cutting width max. 4600 mm
cutting height max. 100 mm
saw blade diameter max. 430 mm

Ideal for small and medium sized companies, as the machine offers high execution speed of the cutting cycle and allows automatic feeding through the high conveyor table. The pusher system with grippers allows to take the workpieces from the high conveyor table without using traversing devices or other systems. The double-sided grippers with lower countersunk element contribute to efficient processing of the materials. The cutting center is thus a valuable addition for companies in the furniture and semi-finished goods industry that want to ensure high productivity and quality.

total connected load approx. 29 kW

weight 9500 kg
